Part Number: SA07.6-F10
Product Name: AUMA Multi-turn SA Actuators
Origin: Germany
Actuators of the SA type range for open-close duty and positioning duty are rated for class A and B or types of duty S2 - 15 min. A special version for longer running is available for the S2 - 30 min duty.
Specification
The modulating actuators of the SAR range are rated for class C or types of duty S4 - 25 %. Special versions for S4 - 50 % and S5 - 25 % are also available.
Design features SA
Torque range from 10 Nm to 32,000 Nm
Output speeds from 4 to 180 rpm
Limit and torque sensing
Available with 3-ph AC, 1-ph AC and DC motors
Handwheel for manual operation
Design features SAR
Torque range from 15 Nm to 4,000 Nm
Modulating torque range from 15 Nm to 1,600 Nm
Max. number of starts 1,200 c/h
Output speeds from 4 to 90 rpm
Limit and torque sensing
Available with 3-ph AC, 1-ph AC motors
Handwheel for manual operation
Common Models:
SG05.1-F04+AM01.1 COM:23016716
SG07.1-F07+AM01.1 COM:23016728
SA07.5-F10+GS160.3+AM01,1 COM:13076636
SGR05.1-F07+AM01.1 COM:23020725
SG05.1-F05+AM01.1 COM:23016720
AUMA GS50.3
AUMA GS63.3
AUMA GS80.3
AUMA GS100.3
AUMA GS125.3
AUMA GF50.3
AUMA GF63.3
AUMA GF80.3
AUMA GF100.3
AUMA GF125.3
AUMA LE12.1
AUMA LE50.1
AUMA Z014.235C/B
AUMA Z024.657
AUMA Z015.909
AUMA Z014.811A
AUMA Z009.636A
AUMA Z013.718C/B
AUMA Z031.910
Our Advantage:
Best possible prices and delivery time
Long time experience in the field
Well trained staff
Own warehouse facilities
Best relationships with branch office of manufacture
Flexible and individual service for you
Cheap and safe forwarder for shipments (air)
Frequently Asked Questions:
Q: Does your goods are new and original?
A: Yes, they are new and original.
Q: How long warranty?
A: One-year warranty.
Q: Does any certificates can be provided?
A: Yes, it depends on what product you request, please check details with our sales.
Q: Varied payment methods.
A: We adopt T/T, alipay and paypal and Currency in EURO,USD,RMB
Q: SHIPPING:
A: We can shipping all over the world.via DHL,UPS,Fedex,TNT and IPS,PDE,BRE,KARAPOST etc.
Our Product Range:
Transmitter, Safety barries, Flow meters, Probe, Sensor, Transducer. Valves,Analysis meter, Positioner, Acuator, etc.
